Potentiometer Signal Isolator: 0-10KΩ 4-20mA 0-20mA 0-5V 10V Output 24VDC

Product Overview

The SW-GP model potentiometer signal isolator is a versatile device designed to convert input signals into output signals, with a wide range of options for different applications. This product supports multiple input types, including 4-20mA, 0-20mA, 0-75mV, 0-5V, and 0-10V, and offers corresponding output options of 4-20mA, 0-20mA, 0-5V, and 0-10V. The device operates on a 24VDC power supply, providing accurate and reliable signal isolation for various industrial processes.

SW-GP Model Features

• Multiple input/output configurations available: 1IN 1OUT, 1IN 2OUT, 1IN 3OUT, 1IN 4OUT, 2IN 2OUT, and 2IN 4OUT
• Input impedance ≤50Ω
• Output load resistance: RL≤500Ω (current), RL≥10KΩ (voltage)
• Insulation resistance ≥100MΩ
• Temperature drift: 0.05%F.S/℃(-20-70℃)
• Dielectric strength: 2500VAC/1min (between input, output and power supply)
• Mounting: DIN35mm rail

Input & Output Specifications

• Input voltage range: 0-10KΩ
• Output voltage range: 0-5V, 10V
• Input current range: 4-20mA, 0-20mA
• Output current range: 4-20mA, 0-20mA
• Power supply: 24VDC
• Accuracy: 0.1%F.S, 0.2%F.S(default)
• Response time: ≤10ms

How to Use Potentiometer Signal Isolator

Connecting Input Signals

Connect the input signal source to the appropriate terminals on the SW-GP model potentiometer signal isolator. Make sure to refer to the product manual for guidance on connecting the correct input type.

Configuring Output Settings

Configure the desired output settings using the provided DIP switches or software interface. Refer to the product manual for instructions on setting up the output configuration.

Key Performance Metrics

Accuracy & Response Time

The SW-GP model potentiometer signal isolator provides high accuracy, with an accuracy of 0.1%F.S or 0.2%F.S (default). It also has a fast response time of ≤10ms, ensuring quick and reliable signal conversion.

Temperature Drift & Dielectric Strength

The SW-GP model potentiometer signal isolator has a low temperature drift of 0.05%F.S/℃(-20-70℃), ensuring stable performance across a wide range of temperatures. It also has a dielectric strength of 2500VAC/1min (between input, output and power supply), providing excellent insulation between the input, output, and power supply.

Installation & Maintenance

Mounting Instructions

Mount the SW-GP model potentiometer signal isolator on a DIN35mm rail using the provided mounting hardware. Refer to the product manual for detailed instructions on mounting the device.

Maintenance Tips

To ensure optimal performance and longevity of the SW-GP model potentiometer signal isolator, follow these maintenance tips:

• Regularly inspect the device for any signs of damage or wear
• Clean the device periodically to remove dust and debris
• Replace any worn or damaged components as needed

Note: This article focuses on the SW-GP model potentiometer signal isolator, which supports 0-10KΩ input signals and offers output options of 4-20mA, 0-20mA, 0-5V, and 10V. The device operates on a 24VDC power supply and is designed for use in various industrial applications.
