Aideepen | 10HZ-150KHZ Square Wave Signal Generator PWM Pulse Frequency and Duty Cycle Adjustable Digital Display Module

Features:1. Wide-range frequency adjustment: Ultra-wide frequency range of 1 Hz–5 MHz2. Continuously adjustable duty cycle: 0.1%–99.9%, high precision3. Automatic power-off save: Parameters are never lost; ready to use upon power-up4. High-definition digital display: Real-time, intuitive display of frequency and duty cycle5. Compact and portable design: Palm-sized, ideal for embedded developmentProduct SpecificationsOperating Voltage: 3.3V–30VAdjustment Method: Encoder adjustmentOperating Current: 20mAFrequency: 10Hz–150kHzDuty Cycle: 0%–100% (1% increments)PWM Upper and Lower Limits: Lower limit 0%–70% / Upper limit 50%–100%Product DescriptionThis module is a low-cost, high-performance PWM pulse signal generator featuring a wide frequency range and adjustable duty cycle. It includes a power-off memory function that immediately saves the set frequency and duty cycle upon configuration, eliminating the need for re-configuration upon the next power-up—a highly convenient feature. It is compact and features a high-resolution digital display. It is ideal for applications requiring PWM signal generation and motor speed control.Applications: Motor speed control, microcontroller development, pulse generator.Package ContentsModule × 1
