TAIFU High-Performance Centrifugal Water Pump 2.0HP/3.0HP (THF Series)

The TAIFU 2200W (3.0HP) Centrifugal Pump is a heavy-duty industrial workhorse designed for high-capacity water transfer. At this power level, TAIFU offers two primary models that prioritize different performance metrics: High Pressure (Head) versus High Volume (Flow).1. The High-Pressure Specialist: THF6B-3This is the most common 3.0HP model for agricultural and residential boosting. It is engineered to push water to significant heights or through long pipe networks.Model: THF6B-3Max Head (Lift): 26 Meters (Approx. 37 PSI)Max Flow Rate: 500 Liters/min ($30 m^3/h$)Fittings: 2" x 2" (50mm) Inlet and OutletBest Use: Irrigation systems with many sprinklers, filling high-rise storage tanks, and construction site water supply.The High-Volume Specialist: TNF130The TNF130 is a "high-flow" pump. It moves double the water volume of the THF series but cannot lift it as high. It features larger 3-inch ports to handle the massive flow.Model: TNF130Max Head (Lift): 13 – 15 MetersMax Flow Rate: 1,000 Liters/min ($60 m^3/h$)Fittings: 3" x 3" (80mm) Inlet and OutletBest Use: Draining flooded areas, rapidly transferring water between large reservoirs, or agricultural "flooding" irrigation.Build Quality & FeaturesBoth 3.0HP models share the same industrial-grade construction:Motor: 100% pure copper windings with an F-Class insulation rating, allowing the motor to run continuously without melting.Impeller: Heavy-duty Cast Iron (or optional Brass in some regions) designed for high torque.Shaft: Stainless steel welded shaft to prevent rust-seizing during periods of inactivity.Protection: IP54 rated (dust and splash-proof), with built-in thermal overload protection to prevent burnout if the pump jams.Critical Installation Tip: PrimingThese are non-self-priming centrifugal pumps.Warning: Never run these pumps dry. You must install a 3-inch or 2-inch Foot Valve at the bottom of your suction pipe and manually fill the pump housing with water (priming) before the first start. If air is trapped in the line, the pump will spin but won't move any water, which can damage the mechanical seal within minutes.WARRANTY INCLUSIONS & EXCLUSIONS ● 7 days replacement against factory defect is subject to approval by our authorized personnel only after diagnosis by our authorized technician.● Warranty does not apply to failures due to; human error, mishandling, misuse of any unit are not cover for replacement.WARRANTY CLAIM● Fill out our warranty card attached to the manual inside the box with general information like Date, Model no., Serial no., and Contact no.● Serial number on the unit must match the one written on the warranty card.● Bring your warranty card or any proof of purchased when claiming the warranty.
