BABEDUO Seko AKL-603 Tekna Evo Chlorinator Solenoid Driven （Dosing Pump & Metering pump)

The SEKO Tekna Evo AKL 603 Series line of chemical metering pumps have been designed for maximum chemical resistance and unmatched performance. SEKO standardized all of there pumps to include PVDF (Kynar) wet ends with solid pure TFE (Teflon) diaphragms and and FPM (Viton) seals. This material configuration covers more than 90% of the chemicals being pumped making this a simple choice for most companies. Control Features have not been overlooked on this model. Manual speed control is achieved via two frequency ranges that allow accurate adjustment from either 1-160 strokes per minute or 1-32 Strokes per minute full scale on the dial indicator. There is also a low level stop input to cut off pump should chemical level run out. Simply connect our drum low level switch to this pumps input terminal. FeaturesFlow rates: from 0.4 to 110 l/h Max back pressure: up to 20 bar Power supply: 100 - 240 Vac - 50/60 Hz Stroke rate: from 120 to 300 strokes/minute Pump head: PVDF Diaphragm: PTFE External Enclosure: PP reinforced with fiber glass protection degree IP65 Manually priming valve Installation kit: Included ApplicationWater Cooling SystemPotable WaterWastewater TreatmentWater TreatmentInstallation Kit1pc - Wall-mounted bracket1pc - Injection valve (PVDF) (G3/8", G1/2")1pc - Foot valve (PVDF)1pc - PVC Suction Tube1pc - PE Delivery Tube1pc - Vertical mounting bracketSpecifications: Input:Low level cutoff terminal for optional level switch Adjustable: -1-160 SPM1-32 SPM in /5 mode Voltage: --Standard 100 - 240 VAC 50/60 Hz Universal Power Supply (Optional cords available upon request)--Optional 24-48 VAC/VDC Call for availability and price Materials of construction:---Head = PVDF Body = PVDF Balls = Ceramic Diaphragm = PTFE Seals = FPM Standard, ---Optional EPDM on request Tubing = 1/4" O.D HDPE, ---Natural Injection Fitting = 1/2" NPT by 1/4" Tubing Compression, PVDF, FPM, S.S. Spring---Foot Valve = 1/4" Tubing Compression, PVDF, FPM, S.S. SpringOutput:29 PSI = 2.11 GPH116 PSI = 1.58 GPH145 PSI = 1.32 GPH174 PSI = 1.06 GPHApplicationWater Cooling SystemPotable WaterWastewater TreatmentWater Treatment
