DAHUA DH-HAC-HDW1509TLQN-A-LED 5MP 2.8MM LENS FULL COLOR HDCVI ANALOG DOME | BUILT-N MIC 20M ILLU DISTANCE

📸 OverviewModel: Dahua DH‑HAC‑HDW1509TLQN‑A‑LED Type: 5 MP Full‑Color HDCVI Analog Dome Security Camera Lens: 2.8 mm fixed (wide angle) LED Illuminator: Built‑in warm light for color imaging up to ~20 m (illuminator distance) Built‑in Microphone: Yes (‑A version) Weatherproof: IP67 (outdoor use) Dahua Technology📊 Key Specifications🔹 VideoMaximum Resolution: 5 MP (2880 × 1620)Output Formats: CVI / TVI / AHD / CVBS switchableFrame Rate: Up to 25 fps at 5 MP (16:9)Also supports 4 MP, 1080p and lower analog standards Dahua Technology🌙 Night / Low‑Light24/7 Full‑Color Imaging (color both day and night)Minimum Illumination: ~0.001 Lux @ F1.0 (color)Warm Light Distance: ~20 m for full‑color night visibilityAuto/manual LED control for night lighting Dahua Technology📷 Lens & OpticsFocal Length: 2.8 mm (wide view)Maximum Aperture: F1.0Field of View (approx): ~112° horizontal at 2.8 mmFixed Iris lens Dahua Technology🔊 AudioBuilt‑in Microphone: Yes (audio recorded along with video) Dahua Technology🛠 Image EnhancementsTrue WDR: ~120 dB3D Noise Reduction (3D NR)BLC / HLC / HLC‑ProPrivacy masking (configurable) Dahua Technology🧰 Build & EnvironmentIngress Protection: IP67 (dust/water resistant)Operating Temperature: –40 °C to +55 °CHousing: Metal core + plastic cover Dahua Technology📐 Size & WeightDimensions: ~97.1 mm × 91.4 mm (Diameter × Height)Net Weight: ~0.24 kg Dahua Technology⚡ PowerSupply: 12 V DC ±30%Max Power: ~4.4 W (with LED on) Dahua Technology🔎 What This Camera Is Best ForColor CCTV at night and day without switching to B/W IR modeWide‑area coverage with a wide‑angle lensBuilt‑in audio (no separate mic required)Outdoor installations with rugged protection✅ Feature Quick List✔ 5 MP Full‑Color video

✔ 24/7 full color night mode

✔ Warm LED illumination (~20 m)

✔ Built‑in microphone

✔ WDR, noise reduction & privacy mask

✔ Supports multiple analog formats

✔ IP67 outdoor rating Dahua Technology
