【From Bulacan】HOMTOOLS HM803A/D Dual Impedance True RMS Digital Multimeter 6000 Count AC/DC Voltage/Current Detection Diode Continuous NCV Resistance/Capacitor Temperature Detection Tool 600mV 6V 60V 600V 1000V 60A 600A 1000A

This is a dual impedance true RMS digital multimeter that integrates AC/DC voltage, AC/DC current, frequency, duty cycle, resistance, capacitance, temperature, diode, continuity NCV、VFD、 Multiple measurements such as surge current. There are also functions such as last time data retention, flashlight, maximum/minimum/relative value, Celsius/Fahrenheit, zero key, etc.Specifications:Brand: HOMTOOLSName: Digital MultimeterTexture of material: ABSDC voltage: 600mV/6V/60V/600V/1000V ± (0.5%+5)AC voltage: 600mV/6V/60V/600V/750V ± (0.8%+5)DC current: 60A/600A/1000A ± (2.5%+5)AC current: 60A/600A/1000A ± (2.5%+5) (Only HM803D)Resistance: 600 Ω/6k Ω/60k Ω/600k Ω/6M Ω/60M Ω± (1.0%+5)Capacitor: 10nF/100nF/1 μ F/10 μ F/100 μ F/1mF/10mF/100mF ± (4.0%+5)Frequency: 10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz ± (1.0%+3)Duty cycle: 1%~99% ± (3.0%+3)Temperature (° C/° F):-40°C~1000°C ±(1.0%+2)-40°F~1832°F ±(1.0%+2)Environmental conditions for use:Safety standards: IEC 61010-1，IEC 61010-2-032: CAT III 1000V / CAT IV 600V IEC 61010-2-033: CAT III 1000V / CAT IV 600VPollution level: 2Altitude:< 2000mWorking temperature and humidity: 0~40 ° C (<80% RH,<10 ° C non condensing)Storage temperature and humidity:- 10~60 ° C (<70% RH, remove battery)Temperature coefficient: 0.1 accuracy/° C (<18 ° C or>28 ° C)Maximum allowable voltage between measuring end and ground: AC750V or DC1000VSampling rate: approximately 3 times per secondDisplay: 6000 count display. Automatically display unit symbols according to the measurement function level.Over range indicator: displays "OL"Battery low voltage indication: When the battery voltage is lower than the normal operating voltage, the battery icon symbol will appear on the display screen.Input polarity indication: Automatically display the "" signClamp head opening size: 40mmAutomatic shutdown time: approximately 15 minutesWeight: Approximately 309 gramsPower supply: 3 x 1.5V AAA batteries (included)Size: 240X85X47mmPacking List:1 * Digital Clamp Table1 * Thermocouple2 * Test line1 * User Manual (English)1 * Storage bag1 * Packaging box3 * 1.5V AAA batteries
