diymore 12V/24V Stepper Motor Driver Forward/Reverse Controller Speed Control Module PWM Pulse Signal Generator

Parameter1. This module is a pulse generator module that provides control signals to the stepper driver. A driver must be installed to control the stepper motor.2. This simple controller + stepper motor driver + stepper motor + DC power supply can form a basic control platform.3. The controller offers three low-frequency signal options via jumper settings: high (5.4 kHz to 160 kHz), medium (540 kHz to 16.6 kHz), and low (80 kHz to 2.4 kHz).4. It can generate pulse signals or PWM signals, selectable via jumper settings.5. Measurement frequency: PUL and common cathode.Different stepper drivers may use different labels: EN = ENA = FREE enable PUL = PULS = CLK pulse DIR = CW = CWW directionCommon anode connection method (A) EN+PUL+DIR+ connected to common anode terminal EN- connected to EN PUL- connected to CLK DIR- connected to DIRCommon cathode connection method (B) EN-PUL-DIR- connected to common cathode terminal EN+ connected to EN PUL+ connected to CLK DIR+ connected to DIRPackage includeModule*1
