diymore 20/24Pin ATX Power Adapter Board Desktop Chassis Power Module Usb Fast Charging Adjustable Voltage Type C

Parameter: ATX power input: 20Pin, 24Pin DC power interface: DC 5.5 * 2.1mm Power output interface: 4 regular USB ports, 1 fast charging USB port, 1 TYPE-C port The output voltage of the wiring terminal includes 6 voltage outputs:+12V, -12V,+5V, 5VSB,+3.3V, VDJ (adjustable output positive pole). PCB board size: 105mm * 65mmPower input: 1. The module board is compatible with standard 20 pin and 24 pin ATX computer power inputs 2. The motherboard is equipped with two DC5.5 * 2.1 inputs, which can be used as a DC power transfer, with one input and one output. It can be powered by a 12V-24V DC power supply or a battery pack/18V solar panel Note: When the DC bus is used as the input voltage, only the USB fast charging port+TYPE-C fast charging port+adjustable voltage output is available. When connected to an external DC power supply, the four regular USB ports on the motherboard are not powered. Power output: 1. The motherboard has 4 regular USB ports, with a maximum output of 5V and 2.1A current per USB (it can start and work normally with a power supply, and there is no problem with the power load). 2. The motherboard has 1 fast charging USB port and 1 TYPE-C (which requires the phone and data cable to support fast charging) as fast charging output interfaces (supporting protocols can be found in the physical test diagram). 3. All USB ports can provide power to devices such as mobile phones, tablets, power banks, flashlights, Bluetooth speakers, smart bracelets, small desk lamps, and aging electronic products. 4. Use high current terminal blocks to solve the problems of loose wiring, low current, and difficult wiring caused by terminal posts and screw type terminals. 5. Use high-power 1050 integrated inductors and 470uF high-capacity high-frequency low resistance capacitors to improve charging efficiency and reduce heat generation and ripple. 6. The output voltage of the wiring terminal includes 6 voltage outputs:+12V, -12V,+5V, 5VSB,+3.3V, VDJ (adjustable output positive pole). 7. Adjustable voltage range of VDJ terminal:=Vin - (0.4V-0.8V-MAX).Motherboard control part: 1. Using a toggle switch makes switch operation more convenient. 2. Reserve wiring terminals that can be externally connected to a 10 port (5V) microcontroller for control. 3. The motherboard comes with a voltage display screen, which displays the output voltage in real-time. 4. Reserve XH2.54 2PIN terminal block, which can be controlled by external microcontroller I0 port (5V), using high current terminal block to solve the problems of loose wiring, low current, and difficult wiring caused by terminal posts and screw type terminal blocks Attention: When the DC mother socket is used as the input voltage, only the USB fast charging port+TYPE-C fast charging port+adjustable voltage output are availablePackage Include: 1X power module 1X shell (optional)
