MPPT Solar Ccontroller 60A/80A/100A12V 24V 36V 48V AUTO Battery Charger with LCDAutomatic VID

MPPT DC 12V/24V/36V/48V AUTO 30A 60A 80A 100A Solar Charge Controller compatible with lead acid/colloid*Caution: Connect the battery first. and then connect the solar panel The sequence cannot be reversed.Can be paired with solar panels (can be connected in series)MPPT 30A:Can be paired with solar panels 50--1440W (can be connected in series)Can contact with 12--48V battery.MPPT 60A:Can be paired with solar panels 50--2880W (can be connected in series)Can contact with 12--48V battery.MPPT 80A:Can be paired with solar panels 50--3840W (can be connected in series)Can contact with 12--48V battery.MPPT 100A:Can be paired with solar panels 50--4800W (can be connected in series)Can contact with 12--48V battery.Description of charging protection Note: Please connect the battery to the controller first, and then the photovoltaic panel to ensure that the battery voltage is higher than (12V battery is higher than 10V; 24V battery is higher than 20V; 36V battery is higher than 30V; 48V battery is higher than 40V), otherwise it will cause voltage Identification error.Clock setting instructions: When the battery is connected, press "▲" "▼" to set the clock table, short press "■" to save.Charging voltage setting instructions: After connecting the battery, after setting the clock and saving, long press "▲" for 3-5 seconds, the screen displays LV as the floating charge voltage, which can be adjusted by pressing "▼"; short press again "▲"HV is to increase the charging voltage, which can be adjusted by pressing "▼"; shortly press "▲" again. F**V is the low-voltage cut-off voltage of the DC load, which can be adjusted by pressing "▼"; after setting Long press "▲" for 3-5 seconds to save and exit.product detailsCharging type: MPPTMax current: 30A/ 60A/80A/100A/Battery type: Lead-acid battery (FLD\ GEL\ SLD) or lithium battery or user battery.System Voltage: Auto 12V / 24V / 36V / 48VAutomatic voltage identification:12V system uses a 15V-23V solar panel.24Vsystem uses a 30V-46V solar panel.36Vsystem uses a 45V-66V solar panel.48Vsystem uses a 60V-90V solar panel.Maximum PV power: 720W / 12V system; System 1440W/24V; 2160W/36V system; 2880W/48V systemElectromagnetic compatibility: AccordtoEN61000, EN55022, EN55024Automatic temperature compensation: -3mV / 2V / oCAmbient temperature: -40℃~+75℃maximum efficiency: 99%Waterproof level: IP21Net weight (kg): 1.1Dimensions (mm):180190mm
