			WHAT IS A HYBEID CERAMIC BEARING?



			A ceramic hybrid bearing is a combination of ceramic balls and bearing quality steel rings.


			Which combine hardened steel rings with rolling elements made of high-performance ceramic materials, are an increasingly popular option for demanding applications.




			TECHNICAL SPECS



			Model: 6000 RS


			Structure: Deep Groove Ball


			Material: Hybrid Ceramic


			Bore Dia (d): 10 mm


			Outer Dia (D): 26 mm


			Width (B): 8 mm


			Closures: Sealed  (2RS)


			Lubrication: Grease


			Clearance: C0


			Dynamic Load Rating (Cr) (Newtons): 4550


			Static Load Rating (Cor) (Newtons): 1950


			Weight: 0.019   kg


			Quantity: 1 Lot = 1 PC



			Special Note:


			---



				1, Sometimes the cages will be different.


				e.g.: 67 series thin-walled bearings, because the inner wall is very thin, will use the crown-shaped iron cage.


				---


				2, the grease and sealed are accept custom-made, so sometimes there are different colors of the rubber sealed.


				If you mind the sealed color, please contact us. We'll confirm the stock for you.


				---



				3, The standard clearance of bearings is ISO standard C0, the United States standard K25, the clearance value is 3-18um;


				If you have special requirements for swinging, please contact us before purchasing to confirm.




		BEARING STRUCTURE



		52100 Chrome Steel  Outer Ring & Inner Ring +


		Si3N4 Ceramic Balls +


		Nylon Cage +


		Grease + Sealed =


		HYBID CERAMIC BEARINGS



			BEARING EXPERIMENTAL DATA



		THE HISTORY OF HYBRID CERAMIC BEARING



		The first time I knew the application of hybrid ceramic bearings was Jacob Csizmadia in 1998 world record for 24 hour in line skating.


		A major factor in achieving the new record of 505 km was that he had, in cooperation with bearing manufacturers SKF, replaced the traditional steel balls in the skates' bearings with ceramic balls.


		In 2004, Jacob Csizmadia founded a ceramicspeed company specializing in ceramic bearing applications.


		Ceramic balls manufactured from Silicon Nitride were invented in the 1970& # 39;s, and were first utilised on a large scale by NASA in the early 1990& # 39;s.


		Several years later ceramic ball bearings also entered usage in Formula 1 motorsport, and a small number of bearing manufacturers began producing hybrid bearings with ceramic balls for use in electrical motors.
