SX440 AVR Red Capacitor: A Comprehensive Guide to Voltage Stabilization

Introduction to Voltage Stabilizing Plates & Automatic Voltage Regulators

What is a Voltage Stabilizing Plate?

A voltage stabilizing plate, also known as a pressure regulating plate, is a device designed to maintain a constant output voltage despite fluctuations in input voltage. It plays a crucial role in ensuring the reliability and performance of various electrical systems.

What is an Automatic Voltage Regulator (AVR)?

An Automatic Voltage Regulator (AVR) is a type of voltage stabilizing plate specifically designed for generators. It automatically adjusts the generator's output voltage to maintain a stable and consistent power supply, even when there are variations in the load or input voltage.

Key Features & Benefits of the SX440 AVR Red Capacitor

High-Quality Construction & Long Service Life

The SX440 AVR Red Capacitor is crafted using high-quality materials and components, ensuring superior performance and reliability. Its robust construction guarantees a long service life, making it a cost-effective investment for your voltage stabilization needs.

Built-In Protection Functions

The SX440 AVR Red Capacitor comes equipped with built-in protection functions such as low-speed, over-excitation, and LAM (Load Angle Monitoring) protection. These features safeguard your generator and its connected equipment from potential damage caused by voltage fluctuations or other electrical issues.

Compact Size & Easy Installation

With its compact size and lightweight design, the SX440 AVR Red Capacitor is easy to install and integrate into existing generator systems. Its user-friendly setup process ensures minimal downtime and maximum efficiency.

Specifications & Technical Details of the SX440 AVR Red Capacitor

Sensing/Power Input Voltage & Frequency

The SX440 AVR Red Capacitor supports a wide range of input voltages, including 190-264VAC for 1-phase, 2-wire systems and 170-220VAC for 3-phase, 3-wire systems. It operates at a nominal frequency of 50-60 Hz.

Magnetic Field Output Voltage & Current

The magnetic field output voltage of the SX440 AVR Red Capacitor is 120 VAD, with a continuous current rating of 2.7A and an intermittent current rating of 6A for 10 seconds.

Pressure Regulation Accuracy & Thermal Drift

The SX440 AVR Red Capacitor offers excellent pressure regulation accuracy, with a regulation range of +/- 1%. Its thermal drift is minimal, at just 0.03% per degree Celsius change.

Applications & Compatibility of the SX440 AVR Red Capacitor

Ideal for Diesel Generator Spare Parts

The SX440 AVR Red Capacitor is an excellent choice for diesel generator spare parts, providing reliable voltage stabilization and protection for your generator system.

Compatible with Various Generator Accessories

The SX440 AVR Red Capacitor is compatible with a wide range of generator accessories, making it a versatile solution for various applications.

Conclusion: Why Choose the SX440 AVR Red Capacitor for Your Voltage Stabilization Needs

The SX440 AVR Red Capacitor is a high-quality voltage stabilizing plate that offers superior performance, reliability, and protection for your generator system. With its compact size, easy installation, and compatibility with various generator accessories, it is an ideal choice for diesel generator spare parts. Choose the SX440 AVR Red Capacitor to ensure stable and consistent power supply for your electrical systems.
