140W Type C Fully Charged Auto Separator Battery Overcharge Protector Fully Charged Intelligent Power-Off For Type-C Devices

User Instructions:

The full-power automatic disconnector judges whether the battery is fully charged or nearly fully charged based on the current and voltage during device charging, rather than synchronizing the power by cracking the device's battery management system. Therefore, when electronic products with displays such as mobile phones, tablets, and laptops are charged while powered on, the displayed 100% battery level does not mean the battery is completely full. Usually, after showing 100%, it takes about 10-50 minutes of trickle charging for the battery to be truly fully charged. Different devices and their battery health conditions will affect the trickle charging time.

Therefore, when the auto-disconnect device charges continuously powered-on electronic products such as mobile phones and tablets in white light mode, it will automatically cut off the power supply about 10-50 minutes after the device shows 100% battery with no operation. For other electronic products without a screen and continuous standby function (such as power banks, electric shavers, children's toys, Bluetooth headsets, etc.), use blue light mode; the power supply will be automatically cut off about 5 minutes after being fully charged.

Two Function Modes (Switch modes by single pressing the button)

1. For Type-C output:White light mode: Suitable for screen-operated and continuously powered-on electronic devices such as mobile phones and tablets.laptops.

2. For Type-C output:Blue light mode: Suitable for non-screen electronic devices such as Bluetooth headsets, power banks, electric shavers, beauty instruments, children's toys,

Please pay attention to selecting the appropriate mode when charging, click the button to switch, and avoid not being able to pop up

Function Test:

During normal charging, press and hold the button for 5 seconds. Release it when the white and blue lights flash alternately.

The auto-disconnect device will automatically cut off the power after 5 seconds. This operation can be used to verify whether the device can disconnect properly

Product Parameters

Model：KH-51

1. Type-C DC: 5V-28V 0A-5A

2. Material: Fire-Resistant PC

3. Size: 4234.519.3mm

4. Weight: 26g
