H807SA 8Ports LED Pixel Controller Artnet To SPI supports Madrix Software LAN Synchrony SD card DMX512 Console for WS2811 WS2812 WS2812b WS2815 Led Strip Light

DescriptionH807SA is an 8 ports output detachable single machine controller that can control up to 8192 points. Supports the Art Net protocol, supports addressing of DMA chips, can connect to the DMA console, and can add or delete DAT files through the local area network.Currently, the driver chips that can be controlled include DMX512, HDMX, APA102, APA102-65536, WS2801, WS2811, WS2812, WS2812, WS2813, TM1812, TM1809, TM1804, TM1923, TM1934, TM1925D, TM1926D, TM1803, TM1814, TM1913, TM1914, TM1926, UCSUCS1903, UCS1909, UCS1912, UCS2903, UCS2909, UCS2912, UCS8904, UCS5603, UCS9812, UCS2603, SK9816, SK6816 12. SM16716, SM16703, SM16709, SM16712, SM16704 SM16714, LPD6803, LPD8806, LPD1882, LPD1889, LPD1883, INK1003, APA104, P943, LC8812, GW6205, QED3110, D9866E, D9866B, D9865C, D9865E, D9865F, D9864B, D9864C, MBI6023, MBI6024, ADT6610, TLC5971, JCS0104, etc.LD1510, LD1512, LD153X (only supports 8bit mode)The supporting software is "LED Programming Software" V4.47 and above.2. Performance characteristics(1) Eight output ports, controlling up to 8192 pixels. Each port can control a maximum of 1024 points.(2) The SD card supports FAT32 and FAT16 formats, and allows up to 64 DAT files.(3) Multiple synchronization control can be achieved through a local area network.(4) You can switch files by sending UDP instructions to network port 2, or obtain the current playing file number, etc.(5) Can connect to the DMA console, supports RGBW, can replace files, adjust speed and brightness, and has fast response time.(6) Supports the Art Net protocol and can directly use software that supports Art Net such as MADRIX and Jinx.(7) Support encryption function for limiting the number of power cycles.(8) Supports addressing of the DMA chip, with built-in counting and internal control testing functions.(9) It can be connected or disconnected, and can be directly connected to a computer network card, router, or main controller.(10) Supports online firmwareFeatures1.H801RS /H807SA both supports ART-NET protocol and can directly use ART -NET software such as M5.0 and JINX! . In Art-Net mode, each port outputs max 6 universes, 8 ports output max 8160 pixels for RGB and 6144 pixels for RGBW2.Eight output ports, in SD card mode(offline mode) control maximum 8192 pixels, each port controls maximum 1024 pixels. but only using led studio or led build software.ftware.3.SD card supports FAT32, FAT16 format; maximum capacity is 64G bytes, stores up to 64 DAT files.4.It can Synchronization control by LAN. It can switch files by sending UDP instructions to Network Port 5, or get the serial number of the playing files.5.H801RS/H807SA can be connected to DMX console, replace file, and adjust speed and brightness and responses quickly6.Supporting Encryption Function of Restricting Power-on Number and DAT File Encryption7.Support set DMX address for DMX chips.Product DisplayNote:1. GND and DAT are for single line chips such as WS28122. GND, CLK and DAT are for double line chips such as APA1023. GND, D- and D+ are for DMX512 chips such as UCS512Working Mode: Online mode Or Offline Mode1. Online mode Online mode includes Art-Net mode and non Art-Net mode1). Art-Net mode In Art-Net mode, H801RS /H807sa supports the following chips: DMX512, DMX512_H, DMX512-RDM, TM1812, UCS1903, SM16703, TM1913, TM1926, TM1914, TM1814, QED3110, APA102, WS2801, LPD6803Note: for those chips that have the same time sequence as chips above, H801RS supports them too. For example H801RS/H807SA supports both WS2812 and WS2811 even though they are not listedConnection method:Note:1. H801RS/H807SA doesn't need a SD card in Art-Net mode2. In this mode, NET2 is input, NET1 is output, see image aboveBasic working procedureFirst, you need to choose the chip model of led lights
