Automotive Engine Parts 1358031G00 13580-31G00 TPS Throttle Position Sensor For Suzuki ATV KINGQUAD 700 750

Product Overview

The 13580-31G00 TPS Throttle Position Sensor is a vital component of the throttle system in Suzuki ATV KINGQUAD 700 and 750 models. It ensures smooth engine performance by accurately measuring the throttle position and sending data to the engine control unit (ECU). This sensor is designed specifically for the 2005-2007 and 2008 model years of the Suzuki ATV KINGQUAD 700 and 750, with engine sizes of 695CC and 722CC, respectively.

Key Features

• Compatible with Suzuki ATV KINGQUAD 700 and 750 models
• Designed for 2005-2007 and 2008 model years
• Engine sizes: 695CC and 722CC
• OE number: 13580-31G00
• OEM quality and reliability

Compatibility

This throttle position sensor is compatible with the following Suzuki ATV KINGQUAD models:

• LT-A750X, Z (K8) King Quad
• LT-A700X (K5-K7) King Quad

Installation Guide

Installing the 13580-31G00 TPS Throttle Position Sensor is a straightforward process, requiring only basic mechanical skills and a few essential tools. Follow these step-by-step instructions to install the sensor safely and effectively.

Required Tools

• Socket wrench set
• Phillips head screwdriver
• Torque wrench
• Wire stripper

Step-by-Step Instructions

1. Disconnect the negative battery terminal to avoid any electrical hazards during installation.
2. Locate the throttle position sensor on the throttle body. It is usually mounted near the throttle cable.
3. Remove the electrical connector from the old sensor by gently pulling it off.
4. Unscrew the sensor from the throttle body using a socket wrench.
5. Remove the old sensor and install the new 13580-31G00 TPS Throttle Position Sensor.
6. Reconnect the electrical connector to the new sensor.
7. Reconnect the negative battery terminal and test the throttle position sensor by starting the engine and checking for proper operation.

Troubleshooting

If you encounter any issues with the 13580-31G00 TPS Throttle Position Sensor, refer to the following common problems and solutions.

Common Issues

• Engine performance issues
• Check engine light illuminated
• Erratic throttle response

Solutions

• Verify proper installation of the sensor
• Check for loose connections or damaged wires
• Consult a professional mechanic if issues persist

Frequently Asked Questions

Is this sensor compatible with other models?

No, the 13580-31G00 TPS Throttle Position Sensor is specifically designed for Suzuki ATV KINGQUAD 700 and 750 models with engine sizes of 695CC and 722CC.

How do I know if my sensor needs replacement?

If you experience engine performance issues, erratic throttle response, or a check engine light illuminated, it may be time to replace the throttle position sensor. Consult a professional mechanic for a thorough diagnosis.

For more information on the 13580-31G00 TPS Throttle Position Sensor, visit our website or contact our customer support team. We are committed to providing high-quality automotive engine parts and exceptional customer service.
