WADFOW 500M / 2000M Cable Tracker: Features & Specifications

Introduction to WADFOW Cable Trackers

Overview of WADFOW 500M & 2000M Cable Trackers

WADFOW is a leading manufacturer of cable trackers, known for their high-quality and reliable products. The company offers two models of cable trackers: the WTP9502 and WTP9504, both designed to meet the needs of professionals working in various industries, including telecommunications, construction, and utilities. These cable trackers are perfect for locating underground cables, measuring maximum altitude, and tracking depths.

Key Features of WADFOW Cable Trackers

WADFOW cable trackers boast several key features that make them stand out from the competition. They include:

• Maximum receiving altitude of 500m (WTP9502) and 2000m (WTP9504)
• Depth of tracking up to 30cm (WTP9502) and 2.5m (WTP9504)
• CE certified
• Easy-to-use interface
• Lightweight and portable design
• Battery-powered operation

Understanding the Cable Tracker Models

WTP9502 Model Specifications

The WTP9502 model has the following specifications:

• Receiver size: 238MMx43MMx26MM / 9.4"x1.7"x1.0"
• Emitter size: 145MMx35MMx25MM / 5.7"x1.38"x0.98"
• Receiver weight: 71g / 0.16lb
• Emitter weight: 79g / 0.17lb
• Maximum receiving altitude: 500m
• Depth of tracking (single loop line): up to 30cm
• Includes 1pc transmitter and 1pcs Receiver
• Powered by 2pcs 9V batteries

WTP9504 Model Specifications

The WTP9504 model has the following specifications:

• Includes 1pc transmitter and 1pc Receiver
• Maximum receiving altitude: 2000m
• Depth of tracking (single loop line): up to 2.5m
• DC/AC voltage: 12~400V
• NCV
• Temperature measurement
• Powered by 2pcs 9V batteries
• Output signal: 125kHz
• Minimum Current: 31mA
• Maximum Current: 115mA

How to Use WADFOW Cable Trackers

Setting Up the Cable Tracker

To set up your WADFOW cable tracker, follow these steps:

1. Unpack the transmitter and receiver.
2. Insert two 9V batteries into both the transmitter and receiver.
3. Turn on the transmitter and receiver.
4. Adjust the sensitivity settings according to your needs.

Tracking Underground Cables

To track underground cables, follow these steps:

1. Hold the receiver close to the ground and move it slowly along the suspected path of the cable.
2. Listen for the beeping sound, which indicates the presence of a cable.
3. Mark the location of the cable using a marker or flag.

Measuring Maximum Altitude & Depth

To measure maximum altitude and depth, follow these steps:

1. Hold the receiver at the desired height or depth.
2. Read the altitude or depth measurement on the display.
3. Record the measurement for future reference.

Conclusion

Summary of WADFOW Cable Trackers' Capabilities

WADFOW cable trackers offer a wide range of capabilities, including locating underground cables, measuring maximum altitude, and tracking depths. They are lightweight, portable, and easy to use, making them perfect for professionals working in various industries.

Final Thoughts on WADFOW Cable Trackers

If you're looking for a reliable and high-quality cable tracker, look no further than WADFOW. With their advanced features and easy-to-use interface, these cable trackers will help you get the job done quickly and efficiently.
