Acrel din rail LCD solar inverter 3 Phase energy meter ACR10R-D24TE4 200A input for real-time power consumption monitoring with 3 open type current transformers

GeneralThe rail-type multi-function electrical instrument with external Rogowski coil and split-core current transformer is applicable for the energy-saving reconstruction project in high energy consumption industries including the smelting, iron and steel, welding and semi-conductor industry. It is also suitable for applications such as the power monitoring of grid-connected cabinet for distributed photovoltaic power cabinet and energy demand management. It boasts of no need of bus removal, easy connection and safe construction, saving reconstruction cost and raising efficiency for the user. It integrates the measurements of all electric parameters (including single-phase or three-phase current, voltage, active power, reactive power, apparent power, frequency and power factor) and comprehensive energy monitoring and examination management. Meanwhile, it also has various peripheral interfaces for the user to choose: the RS485 communication interface with MODBUS-RTU protocol can meet the need of online communication management; the interfaces with switch input and relay output can realize the remote signal and remote control of the circuit breaker switch. It is very suitable for real-time power monitoring system with an LCD display and the panel buttons to realize the setting and control of parameters.Model DescriptionFunctionDimension(Unit:mm)DiagramCertificateContact usKristen MaMarketing DirectorAcrel Co., Ltd.Mobile/WeChat/WhatsApp:+86 182 0218 0327 Email: kristen@acrel.cnHeadquarters: No. 253 Yulv Road, Jiading District, Shanghai, ChinaFactory: No. 5 Dongmen Road, Nanzha Street, Jiangyin City, Jiangsu Province, China
