Acrel 3 Phase AMC72L-E4/KC Electric Data Logger Multi Function Dual Energy Measuring LCD Panel Power Meter RS485 Modbus-RTU 220V

Products DescriptionAMC series AC multi-function meter is a smart meter designed for power monitoring needs of power systems, industrial and mining enterprises, utilities, and intelligent buildings. It integrates measurement of power parameters,such as single-phase or three-phase current, voltage, active power, reactive power, apparent power, frequency, power factor.Main FunctionsPanel OverviewOutline DimensionCut-out DimensionWiring IllustrationAC Voltage Signal (400V AC L-L) Input via direct Connection & AC Current Signal (5A or 1A AC) input via -/5A AC or -/1A AC CTs (3-phase 4-wire)AC Voltage Signal (400V AC L-L) Input via direct Connection & AC Current Signal (5A or 1A AC) input via -/5A AC or -/1A AC CTs (3-phase 3-wire)AC Voltage Signal (100V AC L-L) Input via -/100V AC PTs & AC Current Signal (5A or 1A AC) input via -/5A AC or -/1A AC CTs (3-phase 4-wire)AC Voltage Signal (100V AC L-L) Input via -/100V AC PTs & AC Current Signal (5A or 1A AC) input via -/5A AC or -/1A AC CTs (3-phase 3-wire)Installation Instruction1. Cut out a hole on the object on where we will intall the meter according to dimension of meter referred above.2. Remove the buckle on the meter off.3. Install the meter into the cut-out hole.4. Buckle up and fixed the meter.
