WenQia Light Switch Controller Module 50m Wireless Remote Control Wall Panel Rf 433MHz Breaker 110v 220v 230v 10a for Home Electric

There are various combinations in the options, which are convenient to use, please purchase according to actual needs. Product Application Area

Products can be used in homes, farms, factories, offices, laboratories, supermarkets and so on Remote control Electric curtain \ Water pump \ Fan \ Lamp \ LED light \ bulb \ ventilation device \ Signal transmission Remote control humidifiers, microwaves, coffee machines Remote control Taking Care for the elderly, children

Features: 1:Multi switches Control One/Multi Lights Receiver in the meanwhile

2:Avoid Darkness and Save Energy --Set the remote control at different locations to quickly turn on or off the lights. --Turn the lights on in advance to avoid darkness, Turn off the lights after leaving, save energy.

3:More convenient remote control -- When you wake up at anytime, the wall panel switch is more convenient.and it will not distrube babies and other family members.

4:Multiple control methods

Simple to use How to connect

How to get the signal Step 1: Press the learning button(on the Receiver) twice. Wait for 3 seconds; Step 2: Press one button on the remote control. Wait for 3 seconds. Succeed. How to clear the signal Only one step :Press the learning button(on the Receiver) 8 times. Wait for 3 seconds;

Relay Receiver Board Parameter

Product Type: Single Channel Remote Control Switch

Encoding Type: Intelligent Learning Code 1527

RF Working Mode: Superheterodyne Reception

Modulation Mode:ASK

RF Frequency: 433MHz

Working Mode:Momentary, Toggle and Latched

Input Voltage: AC 90V~250V Max current: 10 Amp

Quiescent Current: 5mA

Receiving Sensitivity: >97dbm

Remote Control Range: >50m (Free Space)

Wired Connection Way: Fixed Wiring Pillar

Output Terminal: L /N

L : Living line

N : Neutral line

Color: White (Outside Shell)

Wall panel Transmitter Parameter

--RF frequency : 433MHz --Support encoding : 1527 Leaning code --Transmitting range : Open space is more than 50 meters --Battery : NO Battery include --Panel fluorescence : Yes

High quality

Relay Reciever ( include shell )

Questions and Answers

1.What kind of battery does wall switch need? --1pcs 27A12V,sir.

2.Can i use my own remote to control this relay? --We suggest that not.Not only the frequency,but also the code(1527) and modulation(ASK) should be same.

3.Do you have a wholesales price? --Of course ,sir.Please contact with us.I will get you the best price

4.Do you have fast shipping method? --Of course ,sir.Please contact with us.

On this product detailed page, there is a demonstration video for your reference.

Package include In this link, there are different options.Each option has a picture .Please according to the picture to select what you need.Products have product manual. Brand story Huizhou Wenqiao Electronic Technology Co.,Ltd, starts on 2020.We have 50-100 workers in our factory.We focus on RF, WiFi +RF, Zigbee products .Our company's mission is to make your life smarter

If you do not understand clearly. Please send us a message to let us know. We will do our best to service each of our customers. Enjoy your shopping!

The products are all producted by our own factory , Our factory can support OEM and ODM, welcome to consult.
