Diymore XYS350H 2.1 Channel 220WX2+350W 5.1 Bluetooth Power Amplifier Board Module High and Low Bass Subwoofer TPA3255 Power Amplifier Chip Supports Sinilink-APP DC18V-38V/10A
Reminder: The production chip of this product is changed from the original TPA3251 to TPA3255, but the chip is replaced, and the function is the same!Product selling point
1: High-definition low-distortion HiFi sound quality
2: Heat sink + fan heat dissipation is safe and worry-free
3: TPA3255 power amplifier chip design
4: Volume adjustment: high-end encoder knob adjustment, smooth feel
5: Protection mechanism: protection against overvoltage, undervoltage, clipping, short circuit, overheating, etc.
Product model: XY-S350H
Product name: 2.1 channel bluetooth audio power amplifier board
Power supply: DC18V-38V/10A and above Bluetooth version: 5.1
Audio channel: 2.1 channel Audio input: Bluetooth + AUX + U disk + USB sound card
Audio output: left and right channels + subwooferFrequency range: 20HZ-20KHZ
Volume adjustment: high-end encoder knob adjustment, smooth feel
The left and right channels are up to 220W/3Ω--36VDC
Large output power: 175W/4Ω--36VDC 100W/8Ω--36VDC
Subwoofer maximum 355W/2Ω--36VDC
Output power: 250W/3Ω--36VDC 195W/4Ω--36VDC
Protection mechanism: protection against overvoltage, undervoltage, clipping, short circuit, overheating, etc.
Unique function: Support Sinilink-APP to modify the Bluetooth name, set the Bluetooth password, turn off/on the prompt tone
Product size: 130mm116mm27mm Product weight: 370 g
Checklist
1*S350H TPA3255 Bluetooth power amplifier board module 1 set
