SMATRUL Wireless Switch RF Mini Electrical 433Mhz RF 10 Key Remote Control Relay Timer Receiver Home Led Lamp ON/OFF 220V

Note: The product you purchased is as shown in the second picture in the link

Main features:

1. Timing function: do not need WIFI or APP, can achieve 4-level timing function

2. 16A high power: suitable for most equipment, safer to use

3. Mini body: can be directly installed in the switch bottom box, maintenance and installation are more convenient

4. The open distance of 100 meters is more convenient to use, and the actual distance is indirect obstacles. The more obstacles, the shorter the distance, the more serious the signal loss.

5. After turning off the power, turn on the power again, the device status is off

6. Support 2-way control: can be used in conjunction with 2-way control switch, and then connected to the home

7. One remote control can be multiple controllers, which is more convenient for home use

Controller parameters:

Voltage: 85~250V, 50-60HZ

Current: 16A

Working frequency: 433.92MHZ

Material: PC flame retardant V0

Size: 59x42x20mm

Study code: EV 1527

Mode: ASK

Receiving distance: 100M open distance

The remote controller is compatible with EV1527 2262 chip. Does not support HCS101, HCS200, HCS300, HCS301 rolling code chip remote control

Remote control parameters:

1. Working voltage: DC 3V

2. Working frequency: 433.92MHZ

3. Remote control distance:

4. Working mode: wireless remote control

5. Coding method: learn to code

6. Modulation method: ASK

7. Size: 110 * 37 *15 (mm)

8. Standard battery, 12V 23A battery, (battery not included)
